Raspberry Pi Compute Module 5

The new standard for embedded computing.

Leverage Raspberry Pi 5’s powerful hardware and efficient software stack in your own custom embedded systems.

Raspberry Pi Compute Module 5 is a system on module that delivers the power of Raspberry Pi 5 in a form factor ideal for embedded applications. Featuring a quad-core Arm Cortex-A76 processor, dual 4Kp60 HDMI output, Gigabit Ethernet, optional fully-certified wireless module providing Wi-Fi® and Bluetooth connectivity, and a variety of RAM and eMMC flash options, Compute Module 5 enables you to leverage Raspberry Pi 5’s powerful hardware and optimised software stack in your own custom systems and form factors.

In comparison with its predecessor, Compute Module 5 features additional I/O interfaces, allowing even more flexibility and providing a greater breadth of options for product and application design. For cost-sensitive applications, Compute Module 5 is also available without eMMC flash.

Newly upgraded, more powerful

- Upgraded processor BCM2712, quad-core Cortex-A76 64-bit SoC, more powerful performance

- More options for RAM (2GB / 4GB / 8GB / 16GB)

- More options for eMMC Flash (0GB (Lite) / 8GB / 16GB / 32GB / 64GB)

- Faster eMMC Flash storage, up to 200 Mbps data rate

- Optional for certified radio module, supports either PCB trace antenna or external antenna, more suitable for industrial applications

- Adopts B to B connectors, most compatible with Compute Module 4

- Onboard Gigabit Ethernet PHY supporting IEEE1588, suitable for network applications

- Onboard PCIe Gen 2 x1 interface, allows connecting more useful modules

Upgraded processor, powerful performance

BCM2712 processor, quad-core Cortex-A76 64-bit SoC, more powerful performance

High speed WIFI and Bluetooth

Dual-band WIFI and Bluetooth5.0 BLE radio module, surf the web anywhere

External antenna support

Supports either PCB trace antenna or external antenna, suitable for industrial applications

Specifications

Onboard Resources

Similar to the CM4, the CM5 has an option for cost-sensitive applications to be supplied without the eMMC fitted; this version is called the CM5 Lite. The form factor of the new CM5 and CM5 Lite is compatible with CM4. CM5 has the same board dimension, 4 x mounting hole, and 2x 100-pin high-density connector at the bottom.

Here is a comparison table of the new Raspberry Pi CM5 vs CM4:

Raspberry Pi has also launched an evaluation board for the CM5 - Raspberry Pi CM5 IO Board:

Documents
